Flexible Shielded PVC Insulation Jacket Electrical Wire with 0.75mm2 Copper Conductor

Name: Flexible Shielded PVC Insulation Jacket Electrical Wire with 0.75mm2 Copper Conductor
Brand: Zhufeng
SKU: RVVP
Price: 1.55 USD
Availability: InStock
Rating: 4.6 (114 reviews)

Product Details

Place of Origin: Hebei, China

Brand Name: Zhufeng

Certification: ISO, CCC, CE, RoHS

Model Number: RVVP

Payment & Shipping Terms

Minimum Order Quantity: 1000 meters

Price: $1.55/meters >=1000 meters

Get Best Price

Product Details

Product Description

Highlight:

Insulation Material:	PVC	Type:	LOW VOLTAGE
Application:	Construction, Industrial, Telecommunication, Computer, Car	Conductor Material:	Copper
Jacket:	PVC	Rated Voltage:	300/300V 300/500V 450/750V
Specification:	0.3mm²/0.5mm²/0.75mm²/1mm²/1.5mm²/2.5mm²/4mm²/6mm²	Number Of Cores:	Multi Cores
Standard:	JB/T8734.5-2012	Transport Package:	Wooden Drum

Insulation Material:	PVC
Type:	LOW VOLTAGE
Application:	Construction, Industrial, Telecommunication, Computer, Car
Conductor Material:	Copper
Jacket:	PVC
Rated Voltage:	300/300V 300/500V 450/750V
Specification:	0.3mm²/0.5mm²/0.75mm²/1mm²/1.5mm²/2.5mm²/4mm²/6mm²
Number Of Cores:	Multi Cores
Standard:	JB/T8734.5-2012
Transport Package:	Wooden Drum

Flexible Shielded PVC Insulation Jacket Electrical Wire with 0.75mm2 Copper Conductor

Product Description

RVVP cable wire characteristics

RVVP cable is also called electrical connection anti-interference soft cable, is a kind of soft conductor PVC insulated line plus a shielding layer and PVC sheath cable, rated voltage is 300/300V generally.

Its texture is very soft, can be bent at will, but not easy to break, in daily life is relatively common, a wide range of applications.Good compatibility and can be used in harsh environments.

It is suitable for communication, audio, broadcasting, sound system, anti-theft alarm system, intelligent automation system, automatic meter reading system, fire protection system, etc., which need anti-interference line connection, efficient and safe data transmission cable.

RVVP CABLE Technical Parameters

1. RVVP implementation standard JB/T8734.5-2012
2. PVC insulation
3. PVC sheath
4. The conductor is multi-core annealed bare copper stranded
5. Stranded composite cable with more than two cores
6. It can be shielded by aluminum foil after cable formation
7. Bare copper wire or tinned copper wire braided shielding net
8. The rated voltage is 300/300V
9. Normal working temperature does not exceed 70 ºC
10. Product CCC CE certification

Specification

Product name	Electrical connection anti-interference soft cable	Insulation	PVC
Model	RVVP	Temperature	70°C
Rated voltage	300/300V	Standard	JB/T 8734.3-2016
Specification	0.3/0.5/0.75/1/1.5/2.5/4/6/10/16mm²	Sheath	PVC
Application	Fire automatic fire alarm system detector lines, household appliances, small power tools, instruments and instruments and power lighting lines, connecting power amplifier and sound equipment, broadcast system transmission amplifier amplification processingof audio signals，etc.	Conductor	high quality Oxygen-free copper
